EDUP Wifi Amplifier 5Ghz 5W Power Wireless WiFi Extender 802.11a/n 6dBi Signal Range Long Range Wi-Fi Repeater Booster for Home

EDUP Wifi Amplifier 5Ghz 5W Power Wireless WiFi Extender 802.11a/n 6dBi Signal Range Long Range Wi-Fi Repeater Booster for Home


Product Description:

The 5.8 GHZ WLAN signal booster is designed for IEEE 802.11a/n Wireless LAN applications.
It adopts the direct sequence spread spectrum (DSSS) and orthogonal frequency division multiplexing (OFDM) technology of WLAN communication.
The product is compatible with time division duplexing (TDD) method of WLAN and using rapid microwave detection technology to provide high linearity amplification. The signal booster can work with most WLAN/Wi-Fi devices and increase the WLAN signal strength, therefore a larger WLAN coverage and more stable transmission rate .

Features:

1. 100X the power, improving the link quality and coverage of certifiedWLAN devices
2. 3.0dBultra-low noise
3.Wide 6v to 16v operating input range
4.working with certified IEEE 802.11a/n Wireless LAN devices
5.Simply plug and play,no software is required

Specifications:

Frequency Range: 5.725~5.85GHz
Operating Voltage: 6~16V
Receiving Gain: 15dB±1
Transmission Gain: 20dB±1
Input Trigger Power: Min: 0dBm Max: 10dBm
Maximum Output Power(P1dB): 37dBm(5W)
EVM: 3%@29dBm 802.11a 54Mbps OFDM 64QAM BW 20MHz
DC Supply Current: 700mA@Pout 29dBm 12V
Noise Figure:﹤ . 3 0dB
TX/RX Switch Time Delay:﹤1us
LED Indicator: Transmitter: green; Receiver: red
Operating Ambient Temperature: -40℃~+70℃
Operating Humidity: up to 95% rel. humidity
Dimension: 82mm×50mm×21mm
Weight: 0.25Kg net

Installation Instructions:

Step1:Disconnect power supply toAP/Router.
Step2:Detach the antenna from your certified wirelessAP/Router
Step3:Connect Rg316 cable to the booster andAP/Router
Step4:Connect the antenna to the other end of the booster
Step5:Connect the power supply to the booster first and subsequently the AP/Router
